Good Weatherability And High Impact Resistance Green Polyurethane Round Belt For Industrial

  • Good Weatherability And High Impact Resistance Green Polyurethane Round Belt For Industrial
  • Good Weatherability And High Impact Resistance Green Polyurethane Round Belt For Industrial
  • Good Weatherability And High Impact Resistance Green Polyurethane Round Belt For Industrial
  • Good Weatherability And High Impact Resistance Green Polyurethane Round Belt For Industrial
Place of Origin China
Brand Name jiuna
Certification ROHS
Model Number Diameter 5mm~15mm
Minimum Order Quantity 10rolls
Packaging Details Inner packing is plastic film .outer packing is carton .
Delivery Time Within 5 working days After receipt of your deposit
Payment Terms T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability 96.000 meters per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Color Green Or As Your Require Material PU
Longth 300m/roll 200m/roll 100m/roll Hardness 85A-90A
Tensile Rate 0.3kg-31.3kg Stretching Rate 1.5%-3%
Highlight

pu round belt

,

pu extruded belt

,

Industrial PU Round Belt
Leave a Message
Product Description

Features:

Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set

PU Cord Belt Application :


  Packing machines,
 Ceramic and stoneware processing plants,
Floor and roof tiles conveying,
 Wood Working machineries,
Textile machines,
 Paper industry machines,
   Food grading machines, other food processing machines.





Items No. φ least radius of gyration stretch rate Maximum tensile rate Hardness length of rolled

DIA

(mm)

 In mm Stretching rate Kg Lbs

Hardness

(A)

Roll

(m)
7mm 2.17 55 1.5-3% 4.1 9.0 85 100
8mm 2.56 65 1.5-3% 5.0 11.0 85 100
9mm 2.95 75 1.5-3% 6.8 15.0 85 50
10mm 2.95 75 1.5-3% 7.7 17.0 85 50
12mm 3.94 100 1.5-3% 12.2 27.0 85 30
15mm 4.72 120 1.5-3% 17.7 39.0 85 30
18mm 5.71 145 1.5-3% 25.4 56.0 85 30
20mm 6.30 160 1.5-3% 31.3 69.0 85 30




Good Weatherability And High Impact Resistance Green Polyurethane Round Belt For Industrial 0
